Mixer analogico a 6 ingressi con DSP per effetti e compressore sui canali microfonici. Il dispositivo USB / SD / BT integrato conferisce ulteriore versatilità, evitando l'esigenza di periferiche aggiuntive.
6 input analog mixer with DSP effects and compressor on microphone channels. The integrated USB / SD / BT device gives further versatility, avoiding the need of additional peripherals.
Table de mixage analogique à 6 entrées avec DSP pour les effets et compresseur sur les canaux microphoniques. Le dispositif USB / SD / BT intégré offre une polyvalence accrue, éliminant le besoin de périphériques supplémentaires.
Technical characteristics
| Inputs | 6 |
|
MIC input channels |
2 |
|
Stereo input channels |
2 |
|
Gain |
min. - max. |
|
MIC |
+6 dB to +50 dB |
|
Line |
+10 dB to -34 dB |
|
EIN |
-100 dB |
|
MIC channel frequency response |
10 Hz - 20 kHz +1/-3 dB |
|
THD MIC channel |
≤ 0.03% |
|
Signal to noise ratio |
80 dB |
|
Output levels |
Max. +27 dB (bal) Max +22 dB (unbal) |
|
Mono channel EQ (Hi) |
12 kHz ±15 dB |
|
Mono channel EQ (Mid) |
2.5 kHz ±15 dB |
|
Mono channel EQ (Low) |
45 Hz ±15 dB |
|
Low Cut |
80 Hz |
|
Compressor |
yes |
|
+48 V Phantom power |
yes |
|
MP3 / USB / SD media player |
yes |
|
DSP effects, 16 programs |
yes |
|
Bluetooth player |
yes |
|
Dimensions |
33 x 22.4 x 9.2 cm |
