B00265 - PE-2400

Power amplifier, class H, 2x 1200Wrms / 4 ohm

1,195.80€ Prezzo di listino (IVA esclusa)

Descrizione
ITENFR

PE-2400 è un amplificatore di classe H piccolo ma molto potente, occupa solo 2U rack, ha un sistema di raffreddamento molto efficiente con la velocità delle ventole variabile e ha diverse combinazioni di potenza di uscita, per soddisfare qualsiasi tua esigenza. Ci sono due input combo (XLR e TRS), con due output XLR che servono da LINK, nel caso si voglia mandare il segnale audio a un altro amplificatore, e tre uscite SPEAKON, per usare l'amplificatore in tre modalità diverse: MONO/STEREO/BRIDGE. In base alla modalità scelta cambia la potenza di uscita: da 2 canali x 800 WRMS/8 ohm a 1 canale x 2800 WRMS/4 ohm (consulta la scheda tecnica per maggiori dettagli). Da una piccola festa a un grande concerto con il PE-2400 sarai sempre pronto a iniziare.

PE-2400 is a small but powerful class H amplifier, it fits in a 2U rack, it has an efficent cooling fan with different speeds, and different power output combinations, satisfying your every need. There are 2 combo inputs (TRS-XLR), both with an XLR output link, in case you want to send the audio signal to another amplifier, and three speakON outputs, so you can use the amplifier in three different ways: mono/stereo/bridge. The power output changes based on what you choose: from 2 channelsx800 WRMS/8 ohm to 1channelx2800 WRMS/4 ohm (see technical specifications). From a small party to a big concert, with your PE-2400 you will always be ready to make it happen.

Le PE-2400 est un amplificateur compact très puissant de classe H, qui occupe un espace de seulement 2U. Il possède un système de refroidissement très efficace avec une vitesse de ventilation variable et dispose de plusieurs combinaisons de puissance de sortie, pour répondre à tous vos besoins. L’amplificateur est doté de deux entrées combo (XLR et TRS), avec deux sorties LINK (XLR) pour envoyer le signal audio à un autre amplificateur, et de trois sorties SPEAKON pour trois modes différents : MONO/STEREO/BRIDGE. Selon le mode choisi, la puissance de sortie change : de 2 canaux x 800 Wrms/8Ω à 1 canal x 2800 Wrms/4Ω (voir la fiche technique pour plus de détails). D'une petite fête à un grand concert, avec le PE-2400 vous serez toujours prêt.

Dati tecnici

  • The Power Edge 'Class H' amplifiers are designed for pure power. Thanks to the big power reserve, excellent limiters and protections they can be used in all kinds of different applications such as discotheques, clubs, mobile audio, P A, rental, theater, ...
  • Very compact housing, only 2U high
  • PE-series can be driven in 2 ohm
  • Power (1 kHz, THD+N<0,1%):
  • In Stereo mode: from 2x 800Wrms in 8 ohm until 2x 1440 Wrms in 2ohm.
  • In Bridged mode: from 1x 2400 in 8 ohm until 1x 2800 W in 4 ohm.
  • So ft start
  • Very efficient cooling using variable speed fans
  • Automatic current limiter
  • Short circuit protection
  • DC fault protection
  • High temperature protection
  • Overload protection
  • Can be used in stereo, bridge and mono mode
  • Balanced inputs with combo connectors
  • Balanced XLR signal outputs for daisy chaining
  • Input sensitivity correction: 0,775V / 1,0V / 1,44V
  • 3 speakON outputs.
General: Application Commercial, DJ & Club, Stage & Rental
General: Dimensions (cm) 48,3 x 8,8 x 4,4 cm
General: Weight ( kg) 26.5
General: Color black
General: Power input AC 240V, 50 Hz
General: Energy Label No
General: Display none
General: Fixation 19" rack mountable
General: RU 2U
General: IP rating indoor
Audio: amplifier class H
Audio: min. frequency ( Hz) 20
Audio: max. frequency ( Hz) 20000
Audio: S/N ratio (> dB) 100
Audio: damping factor (>...) 450
Audio: max. output channels 2
Audio: Wrms 2 ohm stereo, per channel 1440
Audio: Wrms 4 ohm stereo, per channel 1200
Audio: Wrms 8 ohm stereo, per channel 800
Audio: Wrms 4 ohm bridge 2800
Audio: Wrms 8 ohm bridge 2400
Audio: functions bridge mode
Connections: input 3-pin XLR, jack, Schuko CEE 7/7
Connections: output 3-pin XLR, speakON
